320G Skid Steer
320G Skid Steer
- Gross Power: 51.7 kW (69 hp)
- Net Power: 49.4 kW (66 hp)
- Rated Operating Capacity: 994 kg (2,190 lb.)
- Operating Weight: 3246 kg (7,150 lb.)
Description
| Lift Geometry | Vertical | |||
|---|---|---|---|---|
| Fleet Management | Yes | |||
| Precision Guidance | No | |||
| Proximity Guidance | No |
| Engine Manufacturer | Yanmar | |||
|---|---|---|---|---|
| Engine Model | 4TNV98C | |||
| Emission Rating | Tier 4 | |||
| Aspiration | Naturally Aspirated | |||
| Displacement, ltr (Inches³) | 3.3 (203) | |||
| Rated Speed, rpm | 2500 | |||
| SAE Net Power, kW (hp) | 49.4 (66) | |||
| SAE Gross Power, kW (hp) | 51.7 (69) | |||
| Max. Gross Torque, Nm (lbf / ft) | 241 (178) | |||
| Drive Chain Rating [ANSI] | 80 – HD | |||
| Tire size – Standard | 12 – 16.5 – 12 PR SKS |
| Length – No Bucket, mm (inches) | 2850 (112.3) | |||
|---|---|---|---|---|
| Length – With Bucket Foundry, mm (inches) | 2460 (136.3) | |||
| Width – No Bucket, mm (inches) | 1700 (67) | |||
| Overall Height, mm (inches) | 2060 (81.1) | |||
| Ground Clearance, mm (inches) | 240 (9.3) | |||
| Wheelbase, mm (inches) | 1120 (44.2) | |||
| Rear Departure Angle, Degrees | 28 | |||
| Height to Hinge Pin, mm (inches) | 3100 (122.2) | |||
| Dump Angle, Degrees | 43 | |||
| Dump Height – Maximum Foundry, mm (inches) | 2480 (97.7) | |||
| Reach – Max Dump Height Foundry, mm (inches) | 740 (29.2) | |||
| Rollback – Ground Level, Degrees | 33 |
| Fuel Tank, ltr (gallons (US)) | 79 (21) |
|---|
| Rated Operating Capacity – Foundry, kg (lbs) | 994 (2190) | |||
|---|---|---|---|---|
| Tipping Load – Foundry, kg (lbs) | 1989 (4380) | |||
| Axle Torque – Maximum, Nm (lbf / ft) | 6771 (4994) | |||
| Speed – Maximum, kph (mph) | 11.1 (6.9) | |||
| Speed – Maximum Option, kph (mph) | 17.9 (11.1) | |||
| Breakout – Lift Foundry, kN (lbf) | 16.5 (3725) | |||
| Breakout – Bucket Foundry, kN (lbf) | 26.6 (6000) | |||
| Hydraulic Power, kW (hp) | 28.842 (38.6) | |||
| Hydraulic Power – Option, kW (hp) | 41.414 (55.5) | |||
| Pump Output, lt/min (gallons (US) / min) | 78 (21) | |||
| Pump Flow – Option, lt/min (gallons (US) / min) | 112 (30) | |||
| System Pressure, bar (PSI) | 224.08 (3250) |
| Operating Weight – Foundry, kg (lbs) | 3246 (7150) |
|---|
